Utility Control System

TYRE Industry

• PLC system:- Allen Bradley make Compact Logix series PLC and 7 remote I/o Panels. Total I/O 1200.
• HMI Station:- 15 inch :- total 8 nos.
• Scada Station:- Two operator station and one Engineering stations, 250 displays

Reactor and Dryer Temperature Control

Pharma Industry

• 21 CFR Validation
• Hot Redundant PLC Control system:- Allen Bradley make Control Logix series PLC. Total I/O 900./li>
• Safe Zone 1 Operating Station : Three Industrial PCs

OIL Transfer

• PLC system:- Allen Bradley make CompactLogix series PLC and 5nos Micro PLC. Total I/O 800.
• HMI Operator station : 100 displays and 19 HMI’s.
• Scada Station :- One operator station and one Engineering stations

Column Distillation

Pharma Industry

• 21 CFR validation
• PLC system:- Allen Bradley make CompactLogix series PLC Software redundant
• One Operator station 100 displays

Tank Farm

Food Oil Industry

• PLC system:- Siemens make S7-1500 series controller with approx. 850 IO
• One Operator station 2048 tags WinCC runtime and 2 HMI’s.
• Scada:- One operator station and one Engineering stations

ANFD, Reactor, Dryer Control

Pharma Industry

• PLC system:- Siemens S7-1500 PLC with approx. 600 IO
• HART AI for temperature transmitter with reading four different RTD temperature through single HART channel

ANFD, Dryer, Reactor

Pharma Industry

• PLC system:- Siemens make S7-400H series controller with approx. 1000 IO
• 10 Zone-1 remote IO nodes of R-Sthal communicating over Profibus with parallel redundancy for IO’s of Hazardous area

Hot Oil System

Chemical Industry

• PLC system:- Allen Bradley make CompactLogix series PLC Software redundant
• One Operator station 100 displays and one HMI
• Two Vfds and three thyristor with complete control on Modbus.

Heating Chamber

Battery Industry

• PLC system:- Siemens make S7 1200 `series PLC (total 5 nos) , 5 HMI’s
• Central SCADA station 2048 Tags on Profibus network.
• SQL based Batch reporting solutions

Sampling Data Collection and Data Validation

Battery Industry

• PLC system:- Allen Bradley Micro PLC total 3 nos)
• Three local SCADA operator station for data collection
• One Master Operator station for Data Validation.

Folding Machine Lines

Packaging Industry

• PLC system:- Allen Bradley Micro PLC total 5 nos, HMI 5 no Servo Drives and Motors 10 sets
• 35 VFD’s on Modbus communication.
• One Managed Switch for Data integration with higher levels.
